BP 01/A

bp_01_a CODE 1 2 3 4 documents
l/min Us gpm bar psi g oz in out by-pass Material On Pumps Download
1215 0587 100 26,4 170 2465 1200 43,32 G1/2F G1/2F G1/2F
Nickel plated brass
CL – CLW
ELR – EL – ELS
Manual
1215 0568 100 26,4 320 4640 1200 43,32 G1/2F G1/2F G1/2F
Brass

BPL 01

CODE 1 2 3 4 documents
l/min Us gpm bar psi g oz in out by pass Material On Pump Download
1215 0512 200 53 150 2175 3400 120 G1”
NPT		 G1”
NPT		 G1”
NPT
Brass
EL – ELR – ELS
EF – EFR – ES – ESR
Manual

BP250/150 – BP 250/280

CODE 1 2 3 4     documents
l/min Us gpm bar psi g oz in out by pass Material On Pump Download
1215 0627 250 66 150 2175 3120 110,02 G1”F G1”F G1”F
Brass
EL – ELR – ELS
EF – EFR – ES – ESR
GL – GLR
SL – SLR
Manual
1215 0628 250 66 280 4060 3160 111,46 G1”F G1”F G1”F
Brass

BP05 – BP 06

CODE 1 2 3 4 documents
l/min Us gpm bar psi g oz in out by pass Material On Pump Download
1215 0487 450 119 200 2900 6070 214,11 G
1”1/4 F		 G
1”1/4 F		 G
1”1/4 F
Brass
GL – GLR
SL – SLR
MLR – RLR
Manual
1215 0488 450 119 200 4350 6200 218,69 G1”F G1”F G1”F
Brass

BP 60/400 Zero – BP 60/600 Zero

CODE 1 2 3 4 documents
l/min Us gpm bar psi g oz in out by pass Material On Pump Download
1215 0531 60 16 400 5800 2125 74,96 G1/2F G1/2F G1/2F
Stainless steel
CH – ELH – ELHR
EFH – ESH – ESHR
Manual
1215 0532 60 16 600 8700 2130 75,13 G1/2F G1/2F G1/2F
Stainless steel

BP 80/400 – BP 80/640

CODE 1 2 3 4     documents
l/min Us gpm bar psi g oz in out by pass Material On Pump Download
1215 0611 80 21 400 5800 2280 80,42 G1/2F G1/2F G1/2F
Stainless steel
CH – ELH – ELHR
EFH – ESH – ESHR
Manual
1215 0488 80 21 640 9200 2280 80,42 G1/2F G1/2F G1/2F
Stainless steel

BP 100/550 – BP 60/550*

CODE 1 2 3 4     documents
l/min Us gpm bar psi g oz in out by-pass Material On Pumps Download
1215 0632 100 26,4 550 8000 1250 44,09 G1/2F G1/2F G1/2F
Stainless steel
CH – ELH – ELHR
EFH – ESH – ESHR
Manual
1215 0613 100 26,4 550 8000 1300 45,85 G1/2F G1/2F G1/2F
Stainless steel
